Turbo Blowers 150 & 300 kW
Oil-free, wear-free air supply for efficient low-pressure applications.
Designed for wastewater aeration, fermentation, and flotation, KAESER’s PillAerator turbo blowers combine high-speed magnetic bearing technology with efficient direct-drive motors. The result is a compact, quiet, and energy-saving blower system ideal for continuous, maintenance-free operation.
- Magnetic bearings: Oil-free, contact-free and wear-free
- Energy savings: Up to 25% more efficient than conventional blowers
- Maintenance-free motor: No lubrication or bearing changes required
- Quiet operation: Noise levels as low as 74 dB(A)
- Smart monitoring: 9” touchscreen with remote communication options
- Compact design: Plug-and-play with integrated filtration and cooling
- Optional heat recovery up to 20 kW (300 kW model)
150 kW Model
- Flow rate: 1,000 – 7,700 m³/h (up to 128 m³/min)
- Pressure differential: 0.3 – 1.3 bar
- Noise level: Max 74 dB(A)
- Motor speed: Up to 30,000 rpm
- Connection: DN250 / PN10
- Cooling: Closed water circuit
- Dimensions (W×D×H): 1800 × 1525 × 2125 mm
- Weight: 1815 kg
300 kW Model
- Flow rate: 2,800 – 15,800 m³/h (up to 263 m³/min)
- Pressure differential: 0.3 – 1.3 bar
- Noise level: Max 76 dB(A)
- Motor speed: Up to 30,000 rpm
- Connection: DN400 / PN10
- Cooling: Closed water circuit with heat recovery (up to 20 kW)
- Dimensions (W×D×H): 2930 × 2125 × 2155 mm
- Weight: 3785 kg
